Solenvis SL91 MBUS level convertor repeater

Let us help you

For more information about this product, please complete the form below and we will call you back.

Or Call us on:

01189 342607

A signal processor controlled Level Converter from RS232 to M-Bus with remote powering and reading of up to 250 M-Bus devices.

Features

• RS232 interface
• RS232 is fully transparent
• Galvanic isolation between RS232C and M-Bus
• All functions are controlled by a signal processor
• Transmission rates: 300 .to 38400 Baud
• Bit recovery (reproducing bit times)
• Full bus extension according to M-Bus specification
• Automatic measurement of maximum possible baud rate
• Echo suppression
• Switching off the bus upon short-circuit and overcurrent with automatic restart at the end of overcurrent
• Device protection against transient overvoltages on the M-Bus1
• Self protection against peak voltages (indirect lightning protection) on the M-Bus 1
• Self protection against strong electromagnetic fields1
• Collision detect with break signalling
• LED´s for data transmission, maximum bus current and overcurrent / short-circuit
• Power supplied by an external 42VDC plug-in power supply unit or wall-mounted power supply
• The device is CE checked and has the CE mark

• Datasheet
