Solenvis SL90 MBUS Repeater

For more information about this product, please complete the form below and we will call you back.
Or Call us on:

A signal processor controlled M-Bus Booster for network extension.

Bus extension for max. 250 meters
Extension of possible cable length
M-Bus Input and M-Bus Output
M-Bus is fully transparent
Galvanic isolation between M-Bus input and output
All functions are controlled by a signal processor
Transmission rates: 300 .to. 38400 Baud
Bit recovery (reproducing bit times)
Full bus extension according to M-Bus specification
Automatic measurement of maximum possible baud rate
Echo suppression
Switching off the bus upon short-circuit and overcurrent with automatic restart at the end of overcurrent
Device protection against transient overvoltages on the M-Bus1
Self protection against peak voltages (indirect lightning protection) on the M-Bus 1
Self protection against strong electromagnetic fields1
Collision detect with break signalling
LED´s for data transmission, maximum bus current and overcurrent / short-circuit
Power supplied by an external 42VDC plug-in power supply unit or wall-mounted power supply
The device is CE checked and has the CE mark
